SMA6862MZ
ActivePricing
* Estimated pricing for reference only. Final price depends on quantity, availability, and market conditions. Submit an RFQ for an exact quote.
Technical Specifications
| Category | Integrated Circuits (ICs)/Full, Half-Bridge Drivers |
| Product Status | Not For New Designs |
| Operating Temperature | -20°C ~ 150°C (TJ) |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | 24-SSIP Formed Leads |
| Technology | Power MOSFET |
| Interface | Logic |
| Supplier Device Package | 24-ZIP (SMA-24) |
| Voltage - Supply | 20V |
| Current - Output / Channel | 1.5A |
| Current - Peak Output | - |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Output Configuration | Half Bridge (3) |
| Load Type | Inductive |
| Rds On ( Typ) | - |
| Voltage - Load | 400V (Max) |
| Applications | AC Motors |
| E U Ro H S Status | RoHS Compliant |
| R E A C H Status | Vendor is not defined |
| U S E C C N | Provided as per user requirements |
| China Ro H S Status | Green Symbol: Green and environmentally friendly product |
Product Overview
The SMA6862MZ is a full & half-bridge drivers in the LED & Motor Drivers family manufactured by Sanken Electric. This component is currently in active production.
Key specifications include Category: Integrated Circuits (ICs)/Full, Half-Bridge Drivers, Product Status: Not For New Designs, Operating Temperature: -20°C ~ 150°C (TJ), Features: -, Mounting Type: Through Hole.
This device comes in a 24-SSIP Formed Leads package with through hole mounting.
FPGACenter currently has 1.518 units of SMA6862MZ in stock, available for immediate shipment with no minimum order quantity.
Application Areas
Frequently Asked Questions
Is the SMA6862MZ in stock and ready to ship?
Yes, FPGACenter currently has 1.518 units of SMA6862MZ in stock. Orders placed before 3 PM (CST) are eligible for same-day dispatch. No minimum order quantity required.
What package type is the SMA6862MZ available in?
The SMA6862MZ by Sanken Electric is available in a 24-SSIP Formed Leads package with through hole mounting configuration. All parts are original and shipped in manufacturer-standard packaging.
What is the pricing for SMA6862MZ?
Unit pricing for SMA6862MZ starts at $11.90 with volume discounts available for quantities of 10+, 100+, 500+, and 1,000+ units. Submit an RFQ for a customized quote based on your specific quantity requirements.
